SECTION 6 — CUSTOM INFORMATION
6.1
UNIT IDENTIFICATION
Model no.:
Serial no.:
Customer identification:
Calibrated for customer line size of
inches, schedule
6.2
CONFIGURATION
The marked (X) items denote the configuration of this unit, as originally shipped from the factory.
Pipe Connection:
:
1" MNPT connection for FTP (main, larger) probe
:
1" MNPT connection with adapter for RS probe
Q
Hot tap with ________ MNPT connection
Input Power:
:
100-250 Vac, 50/60 Hz
Outputs:
Analog:
Q
8 outputs (4-20mA) for the probe (See Table III)
Digital:
:
Ethernet
Q
RS232/RS422
Software:
:
RV User Interface Software and Rheograph utility on CD
Data Access:
:
Ethernet communication
Portable Data Storage:
:
Portable USB Data Storage Device
Enclosures Shipped:
Cables Shipped:
:
Processor Box
:
5711 Interconnect cable (RS485) -
Q
Distribution Box
:
Cat5 Ethernet cable - 10 ft
Q
Transmitter Box
Q
RS232 communication - 20 ft
6.3
SPECIAL INSTRUCTIONS
The next page shows a sketch of a typical layout for a RheoVac DR system with all components located
near each other on the plant floor. Other configurations can be used, but there are rules as to how an
RS485 signal can be run, so if you are considering the use of significantly different arrangement for your
installation, please contact the factory (614-895-0301) to review your plans.
