Inside of cart, insert end of tank wire (without hole) into back of lower back panel.
end of tank wire
Attach other end to bottom of
front brace with a #8x3/8” self-tapping screw.
Inside of cart, insert tank exclusion wire ends into lower back panel. Attach front right side of wire shelf to the right side
panel with one #8-32x3/8”
one #8-32x3/8”
screw,
screw,
4mm lock washer and 4mm flat washer, shown A. Leg attaches to bottom shelf with
4mm lock washer and 4mm flat washer, shown B.
20
Front brace
#8x3/8”
self-tapping screw
Tank wire
#8-32x3/8”
screw
#8-32x3/8”
screw
4mm lock
Right side
panel
washer
4mm lock
washer
4mm flat
washer
4mm flat
washer
B
A
