CAMERE RESTART: Move the cursor to current item and then click confirm button to reboot the
camera.
 

BACK: Go back to previous menu.



EXIT: Log out system menu.

3.4.3.1 White Balance Setup
WB MODE ： AUTO
R GAIN ： 50
B GAIN ： 50
BACK EXIT
Figure 3-10 White balance
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.

WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as
auto, ATW, indoor, outdoor, and manual and etc. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.



R GAIN: Before you set R GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.



B GAIN: Before you set B GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
 

BACK: Go back to previous menu.



EXIT: Log out system menu.

3.4.3.2 Exposure Setting
AE MODE ：AUTO
GAIN SETTING ：2
SHUTTER ：1/50
IRIS SETTING ：4
EXPOSURE COMP ：8
SLOW SHUTTER ：ON
NEXT PAGE
BACK EXIT
AGC GAIN LIMIT ：2
SLOW SHUTTER LIMIT ：1/25
NOISE REDUCTION ：3
3D NOISE REDUCTION ：OFF
BLC ：OFF
WDR SETTING
NEXT PAGE
BACK EXIT
Figure 3-11 Exposure setting Figure 3-12 Next page
HIGH LIGHT REUDCE ：OFF
AE RECOVERY ：15M
BACK EXIT
Figure 3-13 Next page

AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris priority)/TV
(shutter priority). Please use the left/right button on the keyboard or in the speed dome

terminal menu to set.
o Auto: The gain, iris, shutter are in auto mode.
o Manual: You need to set the gain setting, shutter, and iris setting manually.
o Iris Priorit y (AV): I t is for you t o s et t he iris manuall y. G ain and s hut ter ar e in aut o mode.
o Shutter Priority (TV): It is for you to set the shutter manually, Gain and iris are in auto
mode.

GAIN SETTING: It is to set camera gain. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.



SHUTTER: It is to set camera shutter. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.

11
