Move the cursor to SYSTEM INFORMATION and then click confirm button, you can see the above
interface.
Here you can view dome basic information.
3.4.1.2 Address Information
ADDR TYPE ：HARD
ADDR-HARD ：1
ADDR-SOFT ：0
BACK EXIT
Figure 3-5 Address information
Move the cursor to SITE INFORMATION and then click confirm button.

ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
 

ADDR-HARD: It is an address you set in the dial switch. You can not modify it through software.



ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome address.



BACK: Go back to the previous menu.



EXIT: Log out system menu.


3.4.2 Display Setting
PRESET TITLE ：ON
AZIMUTH DISP ：ON
POSITION ：OFF
INSIDE TEMP ：℃
BACK EXIT
Figure 3-6 Display setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After
completed setup, please click save button to save current setup.

PRESET: Display dome preset title or not. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.



AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.



POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.



INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options:
℃
/F/Off. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.



BACK: Go back to the previous menu.



EXIT: Log out system menu.


3.4.3 Camera Setting
