5.1.3 Field Replaceable Cables
Cable Description From To
17-00083-03
Power cord (GS80) in North
America) AC input box PCI or storage device
17-00442-18
Power cord (all GS160/320 +
GS80) in Europe/Japan AC input box PCI or storage device
17-04009-02 Adapter cable 50 to68 pin SCSI signal cable CD-ROM
17-04541-02 Coax clock cable Clock modules. Clock splitters
17-04563-0x I/O hose cable Local I/O riser Remote I/O riser
–01 expndr cab
–02 sys. box
–04 drawer
17-04709-01 Harness assembly Power subrack Pwr cab bulkhead
17-04710-01 Ribbon cable H-switch clock H-switch
17-04711-01 Power harness Power cab bulkhead Rear QBBs in sys cab 1
17-04711-02 Power harness Power cab bulkhead Rear QBBs in sys cab 2
17-04712-01 50 pin sig cable Power subrack Pwr cab bulkhead
17-04713-01 50 pin sig cable Power cab bulkhead Front QBBs in sys cab 1
17-04713-02 50 pin sig cable Power cab bulkhead Front QBBs in sys cab 2
17-04714-01 Power cable Power subrack Pwr cab bulkhead
17-04715-01 Power cable Power cab bulkhead blower
17-04715-02 Power cable Power cab bulkhead blower
17-04716-01 Power (48V/Vaux) QBB H-switch
17-04716-02 –01 long –02 short
17-04722-01 Power (48V/Vaux) QBB (8-P sys only) Dual output clock& CSB
17-04736-01
Signal cable CSB node ID mod CSB
adapter CSB adapter CSB in H-switch
or distrib board housing
17-04797-01 Signal cable Standard I/O SCSI disk
17-04798-01 Power cable PCI backplane SCSI disk, floppy, CD-ROM
17-04800-01 Signal cable PCI backplane CSB ID module
17-04801-01 Signal cable Standard I/O Std I/O interface
17-04810-01 Signal cable PCI backplane OCP
17-04811-01 Power cable Power subrack(s) OCP
17-04844-01 Power cable Power subrack (dr) Drawer blower
17-04845-01 Power cable Power subrack (dr) Drawer bulkhead
17-04846-01 Power harness Power subrack (dr) Drawer bulkhead
17-04847-01 Ribbon cable Drawer backplane CSB module
17-04847-02 Ribbon cable Drawer backplane CSB module
17-04847-03 Ribbon cable Distrib. board CSB module
17-04847-04 Ribbon cable H-switch H-switch CSB mod.
17-04848-01 Signal cable Power subrack (dr) Drawer
17-04848-02 Signal cable Power subrack (dr) Drawer (upgrade)
17-04849-01 Signal cable Standard I/O Floppy
17-04850-01 Power cable Drawer bulkhead Front of backplane
17-04932-01 Signal cable Standard I/O CD-ROM
17-04936-01 Signal cable CSB adapter CSB adapter
17-04982-01 Power cable H-switch CSB module in
