TABLE OF CONTENTS TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ADDITIONAL ITEMS REQUIRED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
KIT INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
KIT CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tx-R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
BATTERY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CHARGING THE FLIGHT BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
INSTALL THE TRANSMITTER BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . 8
TRANSMITTER CONTROLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Heli-Max TX410 SERVO REVERSING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TURNING THE MODEL ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
FLYING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1QS EXPLODED VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
®
INTRODUCTION INTRODUCTION
Thank you for purchasing the Heli-Max 1SQ Quadcopter. We are certain you
will get many hours of enjoyment out of this model. If you should have any
questions or concerns please feel free to contact us at helihotline@hobbico.
com. For the latest technical updates or manual corrections, visit the Heli-Max
web site at: www.helimax-rc.com
Open the “Helicopters” link, and then select the 1SQ Quadcopter. If there is new
technical information or changes to this model a “tech notice” box will appear in
the upper left corner of the page.
®
SAFETY PRECAUTIONS SAFETY PRECAUTIONS
Follow these safety precautions when operating this or any model
helicopter.
● Keep your face and body as well as all spectators away from the plane of
rotation of the rotors whenever the battery is connected.
● Keep these items away from the rotors: loose clothing, shirt sleeves, ties,
scarfs, long hair or loose objects such as pencils or screwdrivers that may
fall out of shirt or jacket pockets into the rotors.
