3. Use an R/C radio system and components that are in first-
class condition. The FlatOuts Edge 540 ARF requires
specialized radio gear. Refer to the
“DECISIONS YOU
MUST MAKE” section to get an accurate description of the
specialized gear required.
4. You must properly install all R/C and other components so
that the model operates correctly on the ground and in the air.
5. You must test the operation of the model before every
flight to insure that all equipment is operating, and that the
model has remained structurally sound. Be sure to check
connectors often and replace them if they show signs of
wear or fatigue.
Remember: Take your time and follow directions to end
up with a well-built model that is straight and true.
If you’re not already an AMA (Academy of Model
Aeronautics) member, we highly recommend that you join.
In addition to providing liability protection while operating
under the AMA Safety Code, the AMA is the governing body
of model aeronautics in the United States and fights for your
rights as a member of the modeling community. You must
also be an AMA member to fly at R/C clubs chartered by the
AMA–most of which are.
Contact the AMA at the address or toll-free phone
number below.
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
Tele: (800) 435-9262
Fax (765) 741-0057
Or via the Internet at:
www.modelaircraft.org
In the hands of a capable pilot the FlatOuts Edge 540 ARF is
an impressive 3D performer. But for the FlatOuts Edge 540
ARF to perform to its full potential, it must be properly
equipped with all the right gear (servos, batteries, receiver,
speed control). There may be more than one type and brand
of radio equipment that can be used, but based on extensive
testing, following is the equipment we recommend so you
can get the most performance out of your FlatOuts Edge 540
ARF and assemble it as shown in this instruction manual.
With a standard, four-channel radio, the FlatOuts Edge 540
ARF is capable of all the basic 3D maneuvers. However,
some advanced pilots who are already familiar with handling
“flat foamies” may prefer to fly the FlatOuts Edge 540 ARF
with a computer radio capable of endpoint adjustments (for
fine-tuning control throws), exponentials (for “softening” the
throws near the center of the travel), and various mixing
functions (such as rudder-to-elevator mixing for extended
knife-edge flight).
The FlatOuts Edge 540 ARF requires three, sub-micro
servos with a maximum weight of .3 oz [9g] each and a
minimum torque rating of 15 oz-in. Futaba
® S-3108M (micro
connector) servos (FUTM0700) are ideal because they meet
the torque and weight requirements and have a micro
connector that is compatible with the Futaba
Ultra Micro
receiver. Although there may be other servos that will
physically fit in the model, those outside of the recommended
weight and torque specifications will adversely affect flight
performance and are not recommended.
Note: During assembly when it’s time to mount the servos,
you will be instructed to glue them in. Do not be alarmed as
this is a common practice with this type of lightweight, high-
performance model. Should servo removal ever be
necessary for repair, replacement or transfer to another
model, this can be done by prying them out with a hobby
knife or a small screwdriver.
The lightest, four-channel receiver is recommended and
must be compatible with whatever servos will be used (not
all servos are compatible with all receivers–even servos and
receivers within the same brand). The Futaba R-124F
Ultra
Micro receiver is recommended and is compatible with the
3108M servos recommended. Note: Futaba receivers are
sold on high and low bands and come without crystals.
Following are the order numbers for the R-124F receiver
and compatible crystals:
Low Band High Band
(Channels 11-35) (Channels 36-60)
R124F Receiver FUTL0438 FUTL0439
Crystal FUTL62** FUTL63**
** Replace the “**” in the order number for the crystals with
the preferred channel number. For example, if you want to fly
on channel 33, order a low band receiver and crystal
number FUTL6233.
Receiver
Servos
Transmitter
DECISIONS YOU MUST MAKE
Note: We, as the kit manufacturer, provide you with a
top quality kit and great instructions, but ultimately the
quality and flyability of your finished model depends on
how you build it; therefore, we cannot in any way
guarantee the performance of your completed model, and
no representations are expressed or implied as to the
performance or safety of your completed model.
