3
6. You must check the operation of the model before every
fl ight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.
7. If you are not an experienced pilot or have not fl own
this type of model before, we recommend that you get the
assistance of an experienced pilot in your R/C club for
your fi rst fl ights. If you’re not a member of a club, your local
hobby shop has information about clubs in your area whose
membership includes experienced pilots.
8. While this kit has been fl ight tested to exceed normal use,
if the plane will be used for extremely high stress fl ying, such
as racing, or if a motor larger than one in the recommended
range is used, the modeler is responsible for taking steps to
reinforce the high stress points and/or substituting hardware
more suitable for the increased stress.
9. WARNING: The cowl included in this kit is made of
fi berglass, the fi bers of which may cause eye, skin and
respiratory tract irritation. Never blow into a part to remove
fi berglass dust, as the dust will blow back into your eyes.
Always wear safety goggles, a particle mask and rubber
gloves when grinding, drilling and sanding fi berglass parts.
Vacuum the parts and the work area thoroughly after working
with fi berglass parts.
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and fl yability of your fi nished model depends
on how you build it; therefore, we cannot in any way
guarantee the performance of your completed model,
and no representations are expressed or implied as to the
performance or safety of your completed model.
Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.
DECISIONS YOU MUST MAKE
This is a partial list of items required to fi nish the Edge 540
EP ARF that may require planning or decision making before
starting to build. Order numbers are provided in parentheses.
Radio Equipment
A 4-channel radio system with four micro servos and a micro
receiver are required for this plane. The servos and receiver
shown in the manual are Futaba
® S3114 micro servos and
the Futaba R114F micro receiver. Two 6" [150mm] servo
extensions, two 16" [400mm] servo extensions, and a
Y-harness are also required. Order numbers for these items
are provided below.
❏
(4) Futaba S3114 Micro High Torque Servo
7.7g (FUTM0414)
❏
Futaba R114F FM Micro Receiver (Low Band – FUTL0442,
High Band – FUTL0443)
❏
Futaba FM Single Conversion Short Crystal (Low Band –
FUTL62**, High Band – FUTL63**)
❏
(2) Futaba C-25 Extension Slim Wire 150mm (FUTM4506)
❏
(2) Futaba 16" [400mm] Servo Extension Futaba
J (FUTM3955)
❏
Futaba 6" Dual Servo Extension J (FUTM4130)
Motor Recommendation
The recommended motor for the Edge 540 EP ARF is:
❏
Great Planes RimFire ™ 35-30-1250kV Brushless
Out-runner Motor (GPMG4595)
Note: Motors from other manufacturers may work with the
Edge 540 EP ARF, however the included motor mounting
components are designed to work specifi cally with the Great
Planes motor listed.
Propeller
The recommended propeller for the Edge 540 EP ARF when
using the Great Planes RimFire 35-30-1250kV motor is:
❏
APC 10" x 7 Thin Electric Propeller (APCQ4123)
Electronic Speed Control
A brushless electronic speed control (ESC) is required for
this plane. We recommend using the Great Planes Silver
Series 35A Brushless ESC 5V/2A BEC (GPMM1830).
Battery Pack
The Edge 540 EP ARF has been tested with 11.1V LiPo
packs ranging from 1250mAh to 2100mAh. Order numbers
are provided for packs of this size. The lighter 1250mAh pack
is suggested for maximum performance.
❏
Great Planes LiPo 1250mAh 11.1V 20C Discharge
w/Balance (GPMP0609)
❏
Great Planes LiPo 1500mAh 11.1V 20C Discharge
w/Balance (GPMP0613)
❏
Great Planes LiPo 2100mAh 11.1V 20C Discharge
w/Balance (GPMP0617)
Note: Do not use Great Planes LiPo 1500mAh 11.1V 3S 8C
Discharge (GPMP0831). This battery pack is not capable
of supporting the current draw of the recommended
power systems.
