1 Fuselage w/balsa LG cover (two 1/4-20 blind
nuts and five 4-40 blind nuts factory installed)
2 Fiberglass cowl
3 R&L top wing panels w/ailerons
4 R&L bottom wing panels w/ailerons
5 Stab & elevators
6 Fin & rudder
7 Canopy
8 Top, center wing panel
9 R&L fiberglass wing struts
10 R&L aluminum cabanes
11 Rear instrument panel
12 4" [100mm] polished aluminum spinner
(cone, backplate, spacers (2), bolt)
13 R&L adjustable engine mount
14 Battery mount
15 Lower fuel tank mount (optional)
16 Servo tray
17 Cowl ring
18 (3) forward bottom wing joiners
19 (3) aft bottom wing joiners
20 Servo tray brace
21 (2) aft top wing joiners
22 (2) forward top wing joiners
23 (8) guide tube supports
24 Fuel tank w/hardware
25 R&L fiberglass wheel pants
26 Aluminum landing gear
27 (2) 4" [100mm] main wheels
28 (2) fiberglass landing gear fairings
Kit Contents (Photographed)
To order replacement parts for the Great Planes Christen Eagle II ARF, use the order numbers in the Replacement Parts
List that follows. Replacement parts are available only as listed. Not all parts are available separately (an aileron cannot
be purchased separately, but is only available with the wing kit). Replacement parts are not available from Product
Support, but can be purchased from hobby shops or mail order/Internet order firms. Hardware items (screws, nuts, bolts)
are also available from these outlets. If you need assistance locating a dealer to purchase parts, visit
www.greatplanes.com and click on “Where to Buy.” If this kit is missing parts, contact Product Support.
Replacement Parts List
Missing pieces: .......Contact Product Support
Instruction manual: .......Contact Product Support
Full-size plans: .......Not available
ORDERING REPLACEMENT PARTS
Order Number
GPMA2440...................Top Wing Set
GPMA2441 ............Bottom Wing Set
GPMA2442..........................Fuselage
GPMA2443 ..............Tail Surface Set
GPMA2444 ..........Cowl w/Cowl Ring
GPMA2445 ............................Canopy
GPMA2446....................Wheel Pants
GPMA2447 ..................Landing Gear Order Number
GPMA2448 .........................Decal Set
GPMA2449 ..........................Cabanes
GPMA2450 ...........Metal Bracket Set
GPMA2451 .....................Wing Struts
GPMA2452 ................LG Fairing Set
GPMA2453............................Spinner
GPMA2454 ...............Flying Wire Set
GPMQ4245........Tail Gear Assembly
KIT CONTENTS
