Galaxy Audio POWERED MICRO SPOT - Manual (Page 12)

Page 11
POWERED
MICRO SPOT
MS
The MSPA is similar to the Powered Hot Spot, with one major difference;
it's half the size! The MSPA has a 30 watt amplifier, with a universal
power supply. That means this unit can be used anywhere in the world
as it will function on 90-250 VAC (volts AC) at 50/60 Hz. The MSPA
delivers full frequency fidelity thanks to its full range 4.5” speaker.
In addition to the standard AC input, MSPA-DC comes equipped with a
12volt DC input. When AC power is not available, the MSPA-DC can be
plugged into a car's cigarette lighter, or attached directly to a 12 volt
battery using an approved type cable.
For information regarding stand or wall mounting, see MOUNTING
YOUR MICRO SPOT SERIES SPEAKERS. (Page. 13)
CONTROLS/INDICATORS
PA/MSPA-DC
and their operation (Front Panel)
POWER LED
LEVEL CONTROL (for both Inputs)
LOW +/- 12 dB @ 200 Hz
HIGH +/- 12 dB @ 10 kHz
