Flat Equ L/R
This function resets all parametric filters of the Left/Right channel. After pressing ENTER, the
following will be shown:
Press ENTER to confirm, QUIT to cancel.
Copy L to R / R to L
This function copies the settings of one channel to the other. Press ENTER to show the following
message:
Press ENTER to confirm, QUIT to cancel.
EDIT CHANNEL L/R MENU
This sub-menu allows channel parameters editing:
1. Equalizer
2. Hp Filter
3. Lp Filter
4. Delay
5. Mute Channel
Use the ENCODER to select the desired function and press ENTER to access it, press QUIT to
exit.
Equalizer
Here, it’s possible to edit the 15 filters’ gain (+/-15dB step 0.5dB), frequency (20Hz to 20kHz step
1/12 octave), bandwidth (from Q=0.4 to Q=1.00 step 0.05, from Q=1.00 to Q=10 step 0.1 and from
Q=10 to Q=128 step 1).
After selecting Equalizer and pressing enter, the display shows:
Using the ENCODER, it’s possible to select the filter to edit (upper right in the display).
Scrolling all 15 filters, the lower row will show the setting of each. To edit the selected filter, press
ENTER.
The NAVIGATION encoder selects Gain, Freq, and Q.
The PARAMETER encoder varies the parameter value.
HP/LP Filler
This sub-menu edits a Butterworth High/Low Pass filter. Available parameters are frequency (20Hz
to 20kHz step 1/12 octave) and order (filter bypass, 1st order, 2nd order).
Flat R: Are You Sure?
Yes = Enter; No = Quit
Flat L: Are You Sure?
Yes = Enter; No = Quit
CopyRL: Are You Sure?
Yes = Enter; No = Quit
CopyLR: Are You Sure?
Yes = Enter; No = Quit
Right Equ PEQ 01
G01.5 F1K05 Q0.35
Left Equ PEQ 01
G01.5 F1K05 Q0.35
Left Equ PEQ 01
Left Equ PEQ 01
G01.5 F1K05
Left Equ PEQ 01
G01.5
Left Equ PEQ 01
