Brief description
The DS-EQ215 is a graphic/parametric 2-channel EQ with 15+15 filters and channel link
possibility. Its filters are symmetrical, and High/Low pass filters are included. A delay line for each
channel is also available. Its settings are stored into 16 Factory and 16 User Presets. The device
can also be linked to a controller using MIDI, RS232, or USB.
User Interface
At power on, after the initialization phase, the unit shows on the LCD display the following:
On the upper row the preset number and the preset name are visible, on the lower row the
vu-meter shows the input signal level, after the analog GAIN L&R.
To access the main menu the user pushes the ENTER key or rotate the NAVIGATION encoder.
To return to the vu-meters, the user pushes the QUIT key.
Every time the user pushes a key, the LED near it changes its state.
After an encoder rotation or an ENTER key press, the LCD display shows:
Using the PARAMETER encoder, the main menu is accessible through the lower row:
1. LOAD PRESET
2. SAVE PRESET
3. UTILITY FUNCTION
4. EDIT CHANNEL L
5. EDIT CHANNEL R
EDIT CHANNEL R won’t be shown if the system is configured as (Link L& R = ON).
To select a field, use the NAVIGATION encoder. To access a sub-menu press ENTER. To exit,
press QUIT. Enter and quit are also used to confirm user choices.
LOAD PRESET MENU
Here, it is possible to select and load one of the 16+16 available presets.
To select a preset, use the PARAMETER encoder.
If the current preset is the selected one, but has been modified, an asterisk will be shown.
Preset XX: Name Preset
L:|||||||| R:||||||||
Preset XX: Name Preset
Load Preset
Load Preset
01: Name Preset
Load Preset
01: Name Preset *
4
Getting Started Using Front Panel Interface
