Getting Started
As soon as the DS-CP22 is turned ON the device model name will appear in the LCD screen:
And after quickly showing the “Firmware Version X.XXX”, the LCD will show the “Input Level” Page.
The default level is indicated by graphic meters.
When the Input Level reaches clipping, the symbol ”>” will appear (as on channel B in the
example).
From this initial condition, and if an RMS Compressor or a Peak Limiter (or both) are set to be
Active, their compression/limiting activity can be seen on the “Compressor Activity” and “Limiter
Activity” windows. This is accessible from the Input Level page by rotating the NAVIGATION
encoder clock/counter-clock wise once.
If from the Input level window, the user wants to see the RMS Compressor’s activity, rotate the
NAVIGATION Encoder clockwise twice, accessing the following screen:
Here, the compression activity is shown from right to left, indicating the amount of compression.
For the relationship between the bars in the Input Level, Compression/Limiting Activity windows,
Input signal level, and compression depth, refer to the tables.
Getting Started
DS-CP22
Compressor Limiter
Input Level
A: |||||||||| B: ||||||||||
Compressor Activity
A: |||# B: ||||||#
