• FEATURES
The FP-7FGH was specially developed for model helicopters.
Please read this manual carefully before using your new set.
•RF module systems allows one-touch chang-
ing of the frequency band.
•Aileron to rudder mixing is ideal for giant scale
and quarter scale models and gliders.
•Servo reversing switch for each channel allows
reversing of the servo direction by simply flip-
ping a switch.
•Two kinds of dual rates on the aileron, eleva-
tor, and rudder channels. Aileron and elevator
dual rate can be switched simultaneously or
independently.
•Newly designed case and new open gimbal
stick with adjustable tension and lever head.
•Pitch control -> rudder and throttle ->
>
pitch
control mixing.
•Throttle hold function for auto-rotation.
•High and Low pitch cab trimmer permits ad-
justment of the best pitch for hovering and
maneuvering.
•Idle up functions used for static and dynamic
aerobatics.
•Throttle High and Low ATL (Adjustable
Throttle Limiter) allows simple, reliable throttle
linkage hook-up.
•ATV (Adjustable Travel Volume) on AILER-
ON, ELEVATOR & RUDDER channels allows
independent adjustment of the servo left. right,
up. and down throw.
•Trainer system offers an easy training of flight
for beginners. FM systems are not compatible
with AM systems.
•Highest quality aluminum case featuring so-
phisticated designs. The transmitter fits easily
into your hand.
•Neck strap supplied as a standard accessory.
This transmitter has numerous functions which
can be easily operated when using the neck
strap.
RECEIVER FP-R107M
•Pulse noise rejection circuit is invulnerable to
noise.
•Small & high sensitivity 7 channel FM receiver
using a specially developed high sensitivity
monolithic 1C IF amplifier.
•Selective squelch circuit is unaffected by other
transmitters on other bands during simultane-
ous multi-band flights.
•Futaba custom 1C and large capacity capacitor
improve stability against power supply voltage
fluctuations tremendously.
•Same antivibration metal plated pin connectors
as the high-quality J Series.
•Throughole printed circuit board is invul-
nerable to shock and vibration.
SERVO FP-S130
•Small, high-quality five-pole micromotor servo.
High-torque 55.6 oz-in (4 kg-cm). high-speed
(0.24 sec/60°), watertight.
•New indirect drive potentiometer improves
vibration and shock resistance and neutral pre-
cision.
•Futaba low-power custom 1C provides high
starting torque, narrow dead band, and superior
trackability.
•Fiberglass reinforced PBT (polybutylene tere-
phthalate) injection molded servo case is me-
chanically strong, and invulnerable to glow fuel.
•Strong polyacetal resin ultra-precision servo
gear features smooth operation, precise neutral,
and very little backlash.
•Thick film gold plated connector pins ensure
positive contact and improved reliability against
shock and vibration. The housing is polarized to
prevent reverse insertion.
•Four special adjustable splined horns are
available.
