10
Through-the-wall vents shall not terminate over public walkways or over an area where condensate or
vapor could create a nuisance or hazard. Provide vent termination clearances to building or structure
features as follows:
Structure Minimum Clearance
Door, Window or gravity inlet
4 ft. (1.2 m) below
4 ft. (1.2 m) horizontally
1 ft. (305 mm) above
Forced air inlet within 10 ft. (3m)
3 ft. (.91 m) above
Adjoining building or parapet
6 ft. (1.8 m)
Adjacent public walkways
7 ft. (2.1 m) above grade
Horizontal Venting
EACH APPLIANCE MUST HAVE ITS OWN INDIVIDUAL VENT PIPE AND TERMINAL. Do not connect
vent system from horizontally vented units to other vent systems or a chimney
