DVIGear DVI-7525 User Manual
Page 6
-4-
2.1 Specifications (Continued)
HDBaseT
DVI-7520
DVI-7525
Category Cable Type
Recommended: CAT6A S/FTP (550 MHz) AWG 23
Required: CAT5e or better
Compliant with TIA/EIA-568B termination standard
Maximum Extension
Distances
(1)
up to 230 ft. (70 meters) @
1920x1080 / 60p / 36-bit
up to 330 ft. (100 meters) @
1920x1080 / 60p / 36-bit
up to 130 ft. (40 meters) @
4096x2160 / 30p, 1920x1080 / 60p /
48-bit, and 1920x1080 / 120p
up to 230 ft. (70 meters) @
4096x2160 / 30p, 1920x1080 / 60p /
48-bit, and 1920x1080 / 120p
Maximum Pixel Clock Freq.
Supports pixel clock rates up to 340 MHz
Maximum Video Bit Rate
Supports digital signal bit rates up to 3.4 Gbps./color, 10.2 Gbps. total
Gain
0 - 10 dB @ 100 MHz
Resolution Range
800x600 – 1920x1200, 4096x2160 / 30p
Signal to Noise Ratio
> 70 dB @ 100 MHz over 70m cable > 70 dB @ 100 MHz over 100m cable
Return Loss
< -30 dB @ 5 KHz
Total Harmonic Distortion
< 0.005% @ 1 KHz
Min. / Max. Signal Level
< 0.3 Vpp / 1.45 Vpp
Differential Phase Error
±10° @ 135 MHz over 70 m cable
±10° @ 135 MHz over 100 m cable
Propagation Delay
< 7 µs @ 70 meters
< 10 µs @ 100 meters
Power Over HDBaseT (POH)
Fully-compliant implementation of Power over HDBaseT (POH).
Tx unit is a PSE device and Rx unit is a PD device.
Mechanical
Construction
Heavy-duty steel enclosure with jet black finish
Dimensions (W x D x H)
Each Unit: 6.8" x 3.9" x 1.0" (173.1 mm x 100.1 mm x 25.6 mm)
Weight
Tx Unit: 14.5 oz. (411 grams)
Rx Unit: 15.1 oz. (428 grams)
Tx Unit: 14.7 oz. (418 grams)
Rx Unit 15.2 oz. (432 grams)
Environmental
Operating Temp.
Environment: +32° to +95° F (0° to +35° C)
Typical Case Temp.
Tx Unit: 98.6° F (37° C); Rx Unit: 105.8° F (41° C);
(Ambient Environment 30°C, 10 Hours)
Storage Temp.
Environment: -4° to +158° F (-20° to +70° C)
Opr. / Strg. Humidity
10% to 90% (non-condensing)
Regulatory Approvals
TX / RX Units
FCC, CE, RoHS
External AC Power Adapter
FCC, CE, UL, C-UL, CEC, GS, PSE, RoHS
Warranty
Limited Warranty
3 Years Parts and Labor
Accessories
Included
1x User Guide, 1x External AC Power Adapter, 1x IR Transmitter,
1x IR Receiver, 2x 3-pin RS-232 Phoenix Connectors,
4x Mounting Brackets with Screws, 2x HDMI Jack Screws
Optional
Additional AC Power Adapter with USA, Euro, UK, or Australia Plugs (DVI-7520-PS),
IR Receiver (DVI-7360-IR-RX), IR Transmitter (DVI-7360-IR-TX),
19” Rack Mount Kit (DVI-7520-RMK)
Note 1: Maximum cable lengths using recommended CAT6A S/FTP (550 MHz) AWG 23 cable
