-3-
2.0 SPECIFICATIONS
Model DVI-7520 DVI-7525
Extender Set
DVI-7520:
HDBaseT HDMI Extender Set, 70m DVI-7525:
HDBaseT HDMI Extender Set, 100m
Transmitter
DVI-7520-Tx:
HDBaseT HDMI Transmitter, 70m DVI-7525-Tx:
HDBaseT HDMI Transmitter, 100m
Receiver
DVI-7520-Rx:
HDBaseT HDMI Receiver, 70m DVI-7525-Rx:
HDBaseT HDMI Receiver, 100m
Performance
Video
Supports HDMI v1.4, HDCP, and CEC
HDBaseT Class Type HDBaseT Class B HDBaseT Class A
Audio
Supports HDMI embedded audio: up to 7.1 PCM, Dolby Digital TrueHD,
and DTS-HD Master Audio
HDCP Supports HDMI signals with or without HDCP encryption
Control Supports Ethernet (DVI-7525 only), bidirectional IR and RS-232 pass-through
Power Supports local 12VDC power, as well as 48V POH (Tx unit to Rx unit).
EDID EDID of connected display is transparent
Cable Equalization Automatic, adaptive
Supported HDTV Formats Supports HDTV resolutions up to 4096x2160 (4K)
Supported PC Resolutions
Supports all single-link DVI resolutions up to 1600x1200 and 1920x1200,
HDMI resolutions up to 4096x2160 (4K)
Input DDC Signal 5.0 Vpp (TTL)
Input Video Signal 0.5 to 1.0 Vpp
IR Carrier Freq. Range 33-55 kHz @ 5 volts
RS-232 Baud Rate Up to 115,200 baud
Connections / Indicators
HDMI Input / HDMI Output
1x 19-pin Female HDMI connector
HDBaseT Interface 1x RJ45 with 48V POH
IR Remote Control
1x IR IN: 3.5mm Stereo Mini-Jack
1x IR OUT: 3.5mm Mini-Jack
RS-232 1x 3-pin phoenix connector
Ethernet Interface None 1x RJ45
Power 1x Screw-locking 5.5 mm / 2.0 mm female connector
Diagnostic Indicators Power, Status, Link, and HDCP LEDs
Power
Power Consumption
Tx Unit: 10.8 watts (Maximum)
Rx Unit: 10.8 watts (Maximum)
Tx Unit: 11.8 watts (Maximum)
Rx Unit: 11.8 watts (Maximum)
Remote Power 48V POH from Tx unit to Rx unit
External AC Power Adapter Input: 100-240VAC, 50-60Hz / Output: +12VDC @ 1.5A
ESD Protection ± 15 kV
