DLE 35RA - Manual (Page 21)

21
Replacement Parts
Key
No.
Optional Parts (not shown)
Stock
No.
Mfg
Stock
No. Description
1 DLEG3101 35RA-K1 Propeller Washer
2 DLEG3502 35RA-K2 Propeller Drive Nut
3 DLEG3503 35RA-K3 Propeller Drive Hub
4 DLEG3504 35RA-K4 Bearing Front
5 DLEG3505 35RA-K5 Crankcase
6 DLEG3506 35RA-K6 Crankshaft
Spacer
7 DLEG3507 35RA-K7 Bearing Rear
8 DLEG3508 35RA-K8 Woodruff Key
9 DLEG3509 35RA-K9 Crankshaft
10
12
16
24
30
11 DLEG3511
35RA-K11 Carburetor Heat Block
13 DLEG3513 35RA-K13 Reed Valve Assembly
14 DLEG3514 35RA-K14 Reed Valve Petal
15 DLEG3515 35RA-K15 Reed Valve Plate
17 DLEG3517 35RA-K17 Carburetor Complete
18 DLEG3518
35RA-K18 Engine Mount Stand Offs
19 DLEG3519 35RA-K19 Needle Bearing
20 DLEG3520
35RA-K20 Piston w/ Pin
21 DLEG3521 35RA-K21 Piston Pin
22 DLEG3522
35RA-K22 Piston Pin Retainer
23 DLEG3523 35RA-K23 Piston Ring
25 DLEG3525
35RA-K25 Cylinder w/ Gasket
26 DLEG3526 35RA-K26 Spark Plug
27 DLEG3527
35RA-K27 Spark Plug Cap
28 DLEG3528 35RA-K28 Electronic Ignition #6
29 DLEG3529 35RA-K29 Ignition Sensor
31 DLEG3531 35RA-K31 Muffler
32 DLEG3532 35RA-K32 Exhaust Clamp
33 DLEG3533 35RA-K33 Exhaust Tube
34 DLEG3534 35RA-K34 Screw Set
DLEG5525 Onboard Digital Tachometer
DLEG9205 Gas Engine Kill Switch V2.0
DLEQ0301 Prop Drill Guide (30, 35RA)
DLEG3510 35RA-K10 Gasket Set
