12
Specifications
Specifications
The following tables illustrate RocketPort PCI conditions and specifications.
Environmental Condition Value
Air temperature:
System on
System off 0 to 40
°c
-20 to 85
°c
Humidity (non-condensing):
System on
System off 8% to 80%
20% to 80%
Altitude:
0 to 10,000 feet
(0 to 3048 meters)
Electromagnetic Compliance
Emission:
Canadian EMC requirements
CISPR-22/EN55022 Class A*
FCC PART 15: Class A*
Immunity:
EN50082: 801-2 ESD, 801-3 RF, 801-4 FT
Safety:
UL recognized.
Class A*4-port RJ45 model meets FCC Part 15 Class B.
RocketPort PCI Card Specification
Baud rate:
RS-232 DTE (4-port RJ45, 8-port RJ11,
Quad/Octacable models)
RS-232/422 (models with interface
module)
50 to 460.8K baud
(without interface module)
50 to 230.4K baud
(with interface module)
Note: Baud rate is dependent upon hardware and operating system
configuration.
Bus interface PCI
Control by device driver:
Data bits
Parity
Stop bits 7 or 8
Odd, Even, None
1 or 2
Current consumption:
4-port RJ45
8-port RJ11
Quadcable
Octacable
RocketPort 8
RocketPort 16
RocketPort 32
+5V +12V -12V
200 mA 50 mA 10 mA
440 mA 100 mA 160 mA
410 mA 100 mA 160 mA
440 mA 100 mA 160 mA
600 mA 110 mA 160 mA
940 mA 220 mA 320 mA
2.9 A 440 mA 0
