P60 to DTE Cable 7
Type 2: To connect the RS-232 local/remote port of a P60 to a DTE (Data Terminal Equipment or “your PC”) with a 3-pin wiring if you
don’t require hardware flow control.
P60 to DTE Cable
Signal Pin Signal
TxD 3 RxD
RxD 2 TxD
SG 7 SG
RTS 5 CTS
CTS 4 RTS
DSR 20 DTR
DTR 6 DSR
DCD 8 DCD
DB-25
Male RJ45
P60 to DTE Cable
Signal Pin Signal
TxD 2 RxD
RxD 3 TxD
SG 5 SG
RTS 8 CTS
CTS 7 RTS
DSR 4 DTR
DTR 6 DSR
DCD 1 DCD
RJ45
DB-9
Male
P60 to DCE Cable
Signal Pin Signal
TxD 2 RxD
RxD 3 TxD
SG 7 SG
RTS 4 CTS
CTS 5 RTS
DSR 6 DTR
DTR 20 DSR
DCD 8 DCD
RJ45 DB-25
Female
