Overview 2
Overview
The Comtrol P60 RS-232 Surge Protector protects the RS-232 communication line from TOV (Transient Over Voltages) which comes
from lightning, electrostatic discharge, and other forms. TOV is always a major factor that damages components and makes ports
unreliable. To provide a solution for this problem, Comtrol includes a Transient Voltage Suppressor to our I/O ports to clamp surge
voltage to protect ports from TOV.
Specifications
The following list illustrates the P60 conditions and specifications.
• RS-232 RJ45 Connectors supports TxD, RxD, DTR, DSR, RTS, CTS, GND, and DCD.
• RS-232 Terminal Block supports TxD, RxD, DTR, DSR, RTS, CTS, and GND.
• LED Indicators for TxD, RxD, DTR, DSR, RTS, CTS, DCD.
P60 Specification
Surge protection 2000V
Dimension 90mm x 60mm x 21mm
Environmental Condition Value
Operating Temperature 0 to 55 o C
Electromagnetic Compliance Status
Emissions:
RFI Emissions: Class A
EN 55022
FCC Part 15: Class A
Yes
Immunity:
EN 50082-1
Yes
