Comtrol Cable User Manual
Page 26

26 [Documentation number: 2000430 Rev B]
Building Basic Cables
RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly Wire Detail
RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly
Wire Detail
Source DB26 Male
Destination DB25
Female
Base Color/Band Color Twisted Pair #
J1-1
J2-1
Violet/White Ring
No Pair
J1-2
J2-2
Yellow
1A
J1-3
J2-3
Yellow/Gray Ring
1B
J1-4
J2-4
Green
2A
J1-5
J2-5
Green/Gray Ring
2B
J1-6
J2-6
Blue
3A
J1-8
J2-8
Blue/Gray Ring
3B
J1-7
J2-7
Violet
4A
J1-9
J2-9
Violet/Gray Ring
4B
J1-10
J2-10
White
5A
J1-14
J2-14
White/Gray Ring
5B
J1-11
J2-11
Pink
6A
J1-12
J2-12
Pink/Gray Ring
6B
J1-13
J2-13
Red
7A
J1-15
J2-15
Red/Gray Ring
7B
J1-16
J2-16
Orange
8A
J1-17
J2-17
Orange/Gray Ring
8B
J1-18
J2-18
Brown/White Ring
9A
J1-19
J2-19
Red/Brown
9B
J1-20
J2-20
Gray/Red
10A
J1-22
J2-22
Red/Gray
10B
J1-21
J2-21
Gray/Red
11A
J1-23
J2-23
Black/Blue
11B
J1-24
J2-24
Orange/Black
12A
J1-25
J2-25
Black/Orange
12B
J1-26
No Pin
N/A
N/A
