COMP Cams 6535 Hi-Tech Belt Drive User Manual
Instructions
COMP Cams®
3406 Democrat Rd.
Memphis, TN 38118
Phone: (901) 795-2400 Fax: (901) 366-1807
www.compcams.com
Part #163
Revised 08/28/06
#6535 Hi-Tech™ Belt Drive
For Ford 302 & 351 Windsor V8 Engines
Thank you for choosing COMP Cams® products; we are proud to be your manufacturer of choice.
Please read this instruction sheet carefully before beginning installation, and also take a moment to
review the included limited warranty information.
Kit Contents:
• Belt drive main plate with tensioner
• Main plate attaching bolts (5/16" Allen bolts
(4) and 1/4" Allen bolts (2)
• Belt
• Upper gear
• Upper gear hub
• Upper gear hub bolts/washers and nuts (6)
• Upper gear hub seal plate
• Upper gear hub seal
• Seal plate o-ring
• Seal plate attaching bolts (1/4" button head
Allen head bolts (5)
• Lower gear assembly
• Lower gear seal
• Cam retention plate
• Cam retention plate bolts (2) 1/4 countersink
Allen bolts
• Cam bolt/washer and 12 point nut
• Water pump o-rings (2)
• Dowel pins (2)
