COMP Cams® Engine Finishing Kits

(Part #235) Ford 289ci, 351ci Late Model Carbureted

Thank you for choosing COMP Cams® products; we are proud to be your manufacturer of choice.
Please read this instruction sheet carefully before beginning installation; if you have any questions
please call 1-800-999-0853 for help.





















Part # 235

Location Qty

Contents

Description

A

4

Head Dowel

.6745 x .435

B

2

Timing Cover Dowel

.4820 x .550

C

1

Cam Bolt

3/8-16 x 1-1/2 Hex Drive

D

1

Cam Bolt Washer

1.25 x .375 x .25 Washer

E

2

Cam Thrust Plate Bolt

1/4-20 x 5/8 Hex Drive

F

1

Woodruff Key (302ci)

3/16 x 1-13/32

G

1

Woodruff Key (351ci)

3/16 x 1-3/4

H

1

Cam Eccentric - Inner

Cam Eccentric - Inner

I

1

Cam Eccentric - Outer

Cam Eccentric - Outer

J

1

Cam Sprocket Dowel

.3115 x 1.125

All components should be assembled per O.E.M. recommendations.

D

J

F or G

B

A

H, I

E

C

INSTRUCTIONS













The COMP Cams® Engine Finishing Kits are provided to help eliminate searching for misplaced parts, while
providing fresh new parts to meet or exceed O.E.M. specifications. These kits are available for most popular
engine applications. To avoid extra spare parts and cost to the installer, some deviation may occur due to
suggestions by nationwide rebuilders and O.E.M. changes in production. We rely on our customers for
additional feedback in order to provide you with the most complete parts kit available.
