SIDEMINDER WITH ARMS AND SUPPORT PADS
For each quick release toggle (A): Open the
toggle, and while holding the toggle in place,
begin tightening the toggle nut (C) until
finger tight.
Insert the telescoping arms (B) into the tube
openings (D).
Toll Free 800.564.9248
www.comfortcompany.com
509 South 22nd Ave Bozeman, MT 59718
1
2
Adjust the telescoping arms (B) to the desired
distance and angle.
3
Close the toggles (A) to clamp down on the
telescoping arms (B).
Note: If the telescoping arms can still move with the toggles
closed, open the toggles and remove the arms. Then repeat
steps 1-4.
4
Lift the cover flap on the support pads (E) and
attach the pads to the telescoping arms (B) using
the provided pan head screws (F).
5
Adjust pads to the desired distance and angle
and then firmly tighten the screws.
6
IS-SIDEMINDERARMS
REV0413
®
Support pads come in 2 shapes: standard (7003) and contoured (7004) as shown below.
SideMinder® assembly should be installed to the chair before attaching the arms and support pads.
Parts from Kit Bag needed:
F: (4) ¼”-20 x .75” Philips Pan Head Screws
7004 SUPPORT PAD
7003 SUPPORT PAD
A
B
C
F
E
D
