Comfort Company Acta-Embrace Pride - Manual

Toll Free 800.564.9248
www.comfortcompany.com
509 South 22nd Ave Bozeman, MT 59718
IS-ACTAEMPRIDE
REV0813
ACTA-EMBRACE BACK
Parts Included:
1 - Complete Acta-Embrace ™ Back Assembly with Mounting Bracket
To remove current backrest from back plate (A), remove knob (C). 1
Attach bracket (D) to back plate (A) by aligning buttons (B) with cut outs in bracket (D). 2
Remove foam/cover from shell (E). 4
Attach shell (E) to bracket (D) with (4) screws and washers (F) – (G) – (H) as shown in the figure. 5
Re-attach foam/cover to shell (E). 6
1. Feel between the backrest and the user's back for gaps and/or identify areas that require positioning adjustments.
2. Unzip access at the top of the back and remove the stays.
3. Mold the stays to fill in the gaps and/or provide positioning.
4. Reinstall the stays and have the user rest against the Acta-Embrace™ Back.
5. This is an iterative process, continue making adjustments until the proper support and positioning goals have been met.
Thread knob (C) through bracket (D) into back plate (A). 3
The Acta-Embrace™ Back has patented moldable aluminum stays inserted into the cover.
These stays can be molded to meet the contour of the spine.
How to Mold the Aluminum Stays:
™
Attaching an Acta-Embrace Back to a Pride TRU-Balance 3 Power Chair
1 - 5/32” Hex Key
A
B
C
D
E
H
F G
