EZ TRAY INSTALLATION STEPS
Use the Allen wrench (22),
remove the clamp front (3)
from the clamp back (4).
*Keep the two 1/4 20 x 1/2
screws (#6) and 1/4 20 nuts
(#9) for Step 2.
1
The 7”, 9” & 14” poles fit
into each other to form a
custom height for the tray
top.
*Use a combination of one,
two and/or all three poles
(Extended
Pole System)
based on a comfortable
height.
4
Slide the hook (15) over the
top pole. Secure the hook
near the top of the extended
pole system with #16 Philip
screw and #17 nut.
7
Find a location on the wheel-
chair frame to secure clamp.
Reassemble the clamp front (3)
to the clamp back (4) using the
two #6 and #9 nuts. Secure
tightly with Allen Wrench
(22).
2
Insert table top (18) to top of
the pole using one of the
ports on bottom of table
top. If not level re-adjust
clamp. Once level remove
table top.
5
Place table top (18) on the
extended
pole system.
Choose one of the two ports
on the bottom of the table
top based on location prefer-
ence. Insert beverage koozie
(19) into cup holder, if
desired.
8
Using Allen wrench (20)
tighten #7 Cone Set Screw so
the Pole Mount Base (1) is
perpendicular to floor. Using
Allen wrench (21) tighten #5
screw on fork mount (2)
securely so that the Pole
Mount Base (1) opening
faces upwards.
*The tube pole mount base
(1) must be a 90° angle to the
fork mount (2) so the table
top sits flat.
3
Slide two rubber O-rings (13)
over the bottom (base) pole.
Next, slide the cup holder
(14) over the top of the same
pole so it rests on top of the
O-rings (13). The cup holder
can swivel around the pole.
*The cup holder can be used
without adding the table top
for your convenience.
6
The EZ Tray System can be
disassembled and stored in
tote bag if desired. When
not in use remove table top,
poles, and cup holder and
place in tote bag. The non-
intrusive clamp can remain
on wheelchair permanently.
Reassemble table top and/or
cup holder as needed.
*Hook can remain on pole
permanently.
9
MAKE SURE ALL SCREWS (5, 6, 7) ARE TIGHT AND SECURE BEFORE PROCEEDING.
IS-EZTRAY
REV0513
Page 3 of 3
