Chrysler 2008 Aspen - Manual (Page 425)

Cavity
Cartridge
Fuse /
Relay
Mini
Fuse
Description
7 40 Amp
Green Blower Motor Relay
Feed
8 40 Amp
Green JB Feed Acc Delay
9 Spare
10 30 Amp
Pink ASD
11 40 Amp
Green Power Liftgate ( If
Equipped)
12 40 Amp
Green JB Feed / Heated
Rear Glass (EBL)/T-
Case Brake
13 30 Amp
Pink JB Feed RR
14 40 Amp
Green ESP Pump
Cavity
Cartridge
Fuse /
Relay
Mini
Fuse
Description
15 50 Amp
Red JB Feed
16 10 Amp
Red Spare
17 Spare
18 20 Amp
Yellow Fuel Pump
19 20 Amp
Yellow Next Generation Con-
troller (NGC)
20 25 Amp
Clear 115V Power Inverter
21 20 Amp
Yellow ABS Batt
22 20 Amp
Yellow Next Generation Con-
troller (NGC) Batt
424 MAINTAINING YOUR VEHICLE
