F13

10 Amp Red

Ignition Run HVAC

Module/Heated

Rear Glass (EBL)

Relay

F14

10 Amp Red

ABS Module Igni-

tion Run

F15

15 Amp Blue

Battery Feed

Bluetooth

௡,

Compass/Trip

Computer (CMTC),

Sentry Key

௡ Diag-

nostics

F16

20 Amp Yellow

Reconfigurable

Power Outlets

F17

20 Amp Yellow

Ignition Run / Rear

Park Assist / Sec-

ond Row Heated

Seats

F18

20 Amp Yellow

Cigar Lighter Igni-

tion

F19

10 Amp Red

Spare Fuse

F20

15 Amp Blue

Heating & Air Con-

ditioning w/ATC

Only Battery Feed

F21

25 Amp Natu-

ral

Amplifier Battery

Feed

422

MAINTAINING YOUR VEHICLE
