VIZIO 320VL and E370VL User Manual
Using Component Video (Better)
F
Pb/Cb Pr/Cr
---AUDIO^
Ì
n
DVD
OO
1. Turn off the power to your HDTV and DVD player.
2. Connect the component cable (green, blue, and red) from your DVD player to the COMPONENT
jacks on your HDTV.
3. Connect the audio cables (white and red) from your DVD player to the COMPONENT L and R
AUDIO jacks on your HDTV.
4. Turn on the power to your HDTV and DVD player.
5. Select COMP using the INPUT button on the remote control or side of the TV.
Using Composite (AV) Video (Good)
VIDEO —AUDIO-=-
L
H
Q@
DVD
OO
VIDEO R L
1. Turn off the power to your HDTV and DVD player.
2. Connect the Video cable (yellow) from your DVD player to the AV jack on your HDTV.
3. Connect the audio cables (white and red) on your DVD player to the AV L and R AUDIO jacks on
your HDTV.
4. Turn on the power to your HDTV and DVD Player.
5. Select AV using the INPUT button on the remote control or side of the TV.
24
