13
Table 6 — Materials Required for Steel Piping Flange Connections (cont)
LEGEND
Table 7 — Additional Refrigerant Charges Required
UNIT
SIZE
COOLER PIPE FLANGE CONNECTION
FLEX CONNECTOR FLANGE CONNECTION
Circuit A
Circuit B
Circuit A
Circuit B
280
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8)
300
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8)
325
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
350
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
3000A — Accessory Package Part No. 00EFN900003000A (30XA080-200)
3100A — Accessory Package Part No. 00EFN900003100A (30XA220-350)
Item
— Item No. (See Table 2)
LINE SIZE
LIQUID LINE
lb (kg) OF
R-134a REFRIGERANT
PER FOOT (305 mm)
SUCTION LINE
lb (kg) OF
R-134a REFRIGERANT
PER FOOT (305 mm)
in.
mm
lb
kg
lb
kg
1
1
/
8
29
0.41
0.186
—
—
1
3
/
8
35
0.64
0.2903
—
—
1
5
/
8
41
0.89
0.4037
—
—
3
1
/
8
79
—
—
0.05
0.0227
4
102
—
—
0.09
0.0408
*Copper connection.
