Carrier 00EFN900003000A - Manual (Page 12)

12
Table 6 — Materials Required for Steel Piping Flange Connections
LEGEND
*Copper connection.
UNIT
SIZE
COOLER PIPE FLANGE CONNECTION FLEX CONNECTOR FLANGE CONNECTION
Circuit A Circuit B Circuit A Circuit B
140 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
N/A* Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13) N/A*
160 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
N/A* Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13) N/A*
180 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13) Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13)
200 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3000A: Item 15),
Loose Pipe Flange
(3000A: Item 11)
Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13) Accessory supplied:
Flex Connector Flange
(3000A: Item 10),
Flex Connector Flange
O-ring
(3000A: Item 13)
220 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 12)
Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8) Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8)
240 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8) Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8)
260 Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 11)
Field supplied:
ASME B16.9 Stub End 4 in.
(102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100A: Item 9),
Loose Pipe Flange
(3100A: Item 12)
Field supplied:
ASME B16.5 Class 600
Flange 4 in. (102 mm)
Accessory supplied:
Compressor Flange Gasket
(3100: Item 10)
Accessory supplied:
Flex Connector Flange
(3100A: Item 13),
Flex Connector Flange
O-ring
(3100A: Item 8)
3000A — Accessory Package Part No. 00EFN900003000A (30XA080-200)
3100A — Accessory Package Part No. 00EFN900003100A (30XA220-350)
Item
— Item No. (See Table 2)
