1.5 Real Panel Description
Interfaces
Description
Antenna (Fixed / SMA) The Wireless LAN Antenna.
Reset
Push continually the reset button 5 ~ 10 seconds to reset the configuration
parameters to factory defaults.
WPS
Push continually the WPS button 5 ~ 10 seconds to enable the WPS feature.
LAN
The RJ-45 sockets allow LAN connection through Category 5 cables. Supports
auto-sensing on 10/100M speed and half / full duplex, and comply with IEEE 802.3
/ 802.3u respectively.
WAN
The RJ-45 socket allows WAN connection through a Category 5 cable. Supports
auto-sensing on 10/100M speed and half / full duplex, and comply with IEEE
802.3/ 802.3u respectively.
Power
The power jack allows an external power supply connection.
