CNET CWR-854 - Manual (Page 5)

5
1.2 Specification
Standard IEEE 802.11G/B
Frequency Band 2.400GHz ~ 2.484GHz
Radio Type
IEEE 802.11g: OFDM (64-QAM, 16-QAM, QPSK, BPSK)
IEEE 802.11b: DSSS (CCK/DQPSK/DBPSK)
Data Rate (Wireless)
802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 & 6Mbps
802.11b: 11 / 5.5 / 2 & 1 Mbps with auto-rate fall back
Access Protocol CSMA/CA
Number of Operation Channel
2.412~2.462GHz (Canada, FCC) / 11 Channels
2.412~2.484GHz (Japan, TELEC) / 14 Channels
2.412~2.472GHz (Euro, ETSI) / 13 Channels
Operation Mode
AP
AP Client (ad-hoc and infrastructure)
Client
Bridge (point-to-pint and point-to-multipoint)
WDS (Wireless Description System)
Security
64/128bit WEP
WPA (TKIP with IEEE 802.1x)
WPA2 (AES with IEEE 802.1x)
RF Output Power (Typical)
802.11g: up to 14 ± 1 dBm
802.11b: up to 17 ± 1 dBm
Sensitivity
-68dBm @ 802.11g
-80dBm @ 802.11b
Antenna One detachable 5dbi antenna
Dimension (L x W x H) 165 x 118 x 27mm (6.49 x 4.65 x 1.06inch)
Weight 245g
Operation Temperature 0°C ~ 40°C (32° ~ 104°F)
Storage Temperature -20°C ~ 60 °C (-4° ~ 140°F)
Humidity 10% ~ 90% (Non-condensing)
Connector
One antenna connector
One RJ-45 port for WAN
Four RJ-45 LAN ports
Reset to default button
WPS button
Power jack
Power requirement 12V DC, 1A
