U N P A C K I N G A N D I N S T A L L A T I O N I N S T K U C T I O N S
Unpacking and Examining Your Oven
Remove:
1. all packing materials from inside the oven cavity.
Read enclosures and SAVE the Operation Manual.
2. the feature sticker from the outside of the door, if
there is one.
Checkthe oven for any damage, such as misaligned or
bent door, damaged door seals and sealing surfaces.
Door Seals and
broken or loose door hinges and latches and dents
Sealing Surfaces
inside the cavity oron the door. If there is any damage,
do not operate the oven and contact your dealer or
SHARP AUTHORIZED SERVICER.
Choosing a Location for Your Oven
You will useyouroven frequently so plan its location for
ease of use. Do not place the oven on a mat, carpet or
tablecloth or block the ventilation openings. The oven
must be placed on a countertop which is a minimum of
36 inches (91.5 cm) from the floor. Allow at least 2
inches (5.1 cm) on the sides, and 2 inches (5.1 cm)
above the top of the oven (excluding the air vent
opening) for air circulation. Be sure to position oven so
that the rear cannot be touched inadvertently.
Your SuperSteam oven can be built into a cabinet or
wall by itself, or above any electric wall oven, above
warming drawer, above Sharp's Microwave Drawer,
models KB-6002, KB-6015 or KB-6025 or above other
Sharp Microwave Drawer models that specify the
combination of this oven using Sharp's Built-in Kit, RK-
12S30. It cannot be built in above any gas wall oven.
Oven Cavity
Hinges
Latches
SuperSteam Oven
CUTOUT
ELECTRIC WALL OVEN/
WARMING DRAWER/
MICROWAVE DRAWER
CUTOUT
Illustration 1
Referto Illustration 1 for proper location when building in above an electric wall oven, a warming drawer or SHARP
Microwave Drawer. Carefully follow both the electric wall oven/warming drawer/microwave drawer installation
instructions and Sharp's Built-in Kit Instructions. Be sure that the clearance of the floor between the SuperSteam
Oven and the electric wall oven/warming drawer/microwave drawer is a minimum of 2 inches (5.1 cm).
Ordering a Built-in Kit
If your dealer does not stock the kit. It can be ordered directly from the Sharp Accessories and Supplies Center.
Have your credit card number available and call toll-free: 1 -800-237-4277 forordering the kit, RK-12S30 to be sent
to your address.
The kit includes ducts and finish trim strips and easy-to-follow instructions for installation as well as the location
of the power supply.
