FEPIM Specifications
A-2
Figure A-2. FE-100FX
The transmitter power levels and receive sensitivity levels listed are Peak Power
Levels after optical overshoot. A Peak Power Meter must be used to correctly
compare the values given above to those measured on any particular port. If
Power levels are being measured with an Average Power Meter, add 3 dBm to the
measurement to compare the measured values to the values listed above.
Table A-1. FE-100FX Specifications
Cable Type Worst Case Budget Typical Budget
50/125 µm fiber 6.0 dB 9.0 dB
62.5/125 µm fiber 9.0 dB 12.0 dB
100/140 µm fiber 15.0 dB 18.0 dB
FE-100FX SP
