4-3
LANVIEW LEDs
The function of the Port Receive LEDs is listed in Table 4-4 .
The function of the Port Transmit LEDs is listed in Table 4-5.
Table 4-4. Port Receive LEDs
LED Color State
Green Link, no activity port enabled
Green (Blinking) Link, port disabled
Yellow (Flashing) Link, activity, port enabled (flashing to steady on indicates rate)
Red Fault
Off No link, (port disabled)
Table 4-5. Port Transmit LEDs
LED Color State
Green (Flashing) Data activity (flashing to steady on indicates rate)
Yellow (Blinking) Port in standby state
Red (Flashing) Collision (with collision rate)
Red Fault
Off No activity, port can be disabled or enabled
