Page 28
Operation
3-4
Figure 3-2. VLAN-based Network
VLAN Domains
VLAN domains consist of groups of interconnected VLAN switches separated by
routing devices. Figure 3-3 shows such an arrangement. Each group of switches
constitutes a VLAN domain.
Figure 3-3. VLAN Domains
Endpoints on VLAN 1
Endpoints on VLAN 2
SFS Network
LAN A
LAN B
SFS Network
VLAN Switch
VLAN Switch
VLAN Switch
SFS Network
VLAN Switch
VLAN Switch
VLAN Switch
Routing Device
VLAN Domain
VLAN Domain
