4-1
Chapter 4
LANVIEW LEDs
The front panel LANVIEW LEDs indicate the status of the module and may be
used as an aid in troubleshooting. Figure 4-1 shows the LANVIEW LEDs of the
9H423-28 module.
Figure 4-1. The LANVIEW LEDs
Port
Transmit
FAST ENET
9H423-28
CPU
SMB
INB
FAST ENET
ETHERNET
28
27
26X
25X
24
System Status
INB Transmit
INB Receive
Port
Receive
