2-1
Chapter 2
Installing the 9H423-28 Module
The 9H423-28 module occupies a single slot in the SmartSwitch 9000 chassis.
Install the modules by following the steps starting below.
Unpacking the Module
1. Carefully remove the module from the shipping box. (Save the box and
packing materials in the event the module must be reshipped.)
2. Remove the module from the plastic bag. Observe all precautions to prevent
damage from Electrostatic Discharge (ESD).
3. Carefully examine the module, checking for damage. If any damage exists,
DO NOT install the module. Contact Cabletron Systems Technical Support
immediately.
Installing an FEPIM
The 9H423-28 provides a slot for a Cabletron FEPIM (Fast Ethernet Port Interface
Module). The 9H423-28 SmartSwitch module is shipped without FEPIMs. To
install an FEPIM, follow the procedure below:
1. Remove the module if it is installed in the SmartSwitch 9000 chassis.
2. Remove the two screws securing the plate on the side of the FEPIM slot.
The INB Terminator Modules must be installed on the rear of the chassis before
powering up this module. Refer to the INB Terminator Modules Installation
Guide
for information and installation procedure.
NOTE
