HOW TO USE
TIME AND STATUS DISPLAY
The Time and Status Display shows the estimated time
remaining, cycle progress, and vent status. When the dryer is
turned on, the display will illuminate.
m
z
o
r
(Â
X
Normal Small Load
Délicates
Express Dry
Touch Up
Alr/Rack Dry
e
Damp Dry
Guard Siqnal
a Q
«ifl
I High
I Medium
1
Low
Temp
I Extra Dry
; Damp Dry
Dry Level
1 60
50
40
30
20
I
Loud
Soft
Off
START/PAUSE
Timed Dry
Ô
^ ESTIMATED TIME REMAINING
When a cycle is selected, the display will indicate the
default time for that cycle. Once the cycle is started,
the estimated time will be displayed. This displayed
time may fluctuate during the cycle depending on the
conditions of the load in the dryer.
© LINT FILTER INDICATOR
The dryer automatically detects reduced airflow
caused by a full lint filter. The Check Lint Filter indica­
tor will light before each load as a reminder to check
the lint filter before starting each load for maximum
efficiency. Always clean the lint filter before every
cycle.
0 CYCLE STATUS INDICATOR
This portion of the display shows which stage of the
drying cycle is currently underway (DRY, COOLING,
or WRINKLE GUARD).
© CHECK VENT INDICATOR
(DUCT BLOCKAGE SENSING SYSTEM)
The CHECK VENT duct blockage sensing system
detects and alerts you to blockages in the ductwork
that reduce exhaust flow from the dryer. This light
does not indicate any problems with your dryer. If this
light blinks, it indicates that your home's exhaust sys­
tem has a serious restriction, which is not covered by
your dryer's warranty. Call 1-800-4-MY-HOME® for
information regarding duct cleaning services offered
through Sears.
© CONTROL LOCK INDICATOR
When Control Lock is set, the Control Lock indicator
will appear and all buttons are disabled. This pre­
vents children from changing settings while the dryer
is operating.
