DRYER TIMER
To test the timer contacts, select the contacts to be tested; in this case, TM-OR.
Using the cycle sequence chart as a reference, turn the timer to the position where the contacts will be
closed. (AUTO HI HEAT)
E LECTRIC AND GAS DRYER TIMER SCHEDULE
SWITCH
CLOSED
CYCLE
AUTO-HI HEATAUTO-LO HEAT AIR OFF TIMED-HI TIMED-LO
TM-WB
BK-BU-V
BK-BU
BK-R
1 t :'
. t
[EITHER NOT BOTH H DOESN’T MATTER ^ CLOSED
There should be continuity between the contacts.
Turn the timer to a position where the contacts are open. (TIMED-HI)
There should be no continuity between the contacts.
OPEN
o-A/vVo-
22
