Washer Mechanism Removal

1. Remove the two (2)

washer retaining

bolts.

(Fig. 14)

Fig. 14

Retaining Bolts

2. Remove the Motor Wiring and Wiring Harness Clip.

(Fig. 15)

Fig. 15

Motor Wiring

Harness

3. Remove the Drain Hose from the retainer

(Fig. 16)

Drain

Hose

Retainer

4. Remove the Pressure Hose.

(Fig. 17)

Fig. 16
