WHEEL AND WHEEL PANTS
1. Collect the following items:
(2) 5-32 x 1-1/4” Axle with Locking Nut
(4) 5/32 Wheel Collars
(6) 6-32 x 1” Cap Screws
(2) 4-40 Blind Nuts
(2) 4-40 x 1/2” Button Head Screws
(2) 3-1/4” Wheels
(2) Landing gear legs
3.
Mount the axle to the landing gears.
8
FUSELAGE HATCH
The top front half of the fuselage is a hatch. Remove
the 4-40 socket head bolts on the side of the fuse-
lage to disengage the hatch.
2. I nsert the gear legs through the slots in the
fuselage side.
Use the six 6-32 x 1” bolts to secure the gear.
The blind nuts are already installed in the
fuselage.
Be sure and use a thread lock on the bolts.
