12
Balancing
Your model should balance 2-1/2” back from the leading edge of
the wing next to the fuselage.
Control Set Up
Turn on your transmitter and plug in the receiver
battery. Center all the control surfaces (rudder,
elevator & aileron). If required by your speed
control this is the time to program it for your
use.
Control Travel
Aileron up / down 1/2”
Elevator up / down 3/4”
Rudder Right / Left 1”
Propeller
Install the prop adapter and your propeller at
this time. We used a 9 x 4.7 APC prop for our
motor, battery and speed control setup.
Caution:
The propeller can start turning any
time the receiver battery is plugged
in.
Decal Locations
1. Using glass cleaner and a soft cloth, clean the model surface thoroughly before applying decals.
Cut the decal sheets apart in sections, as needed.
Peel the backing off the decal and apply the decal to the plane.
