Page 35
Chapter 2: Hardware Installation
2-5
Intellicon-NT960/PCI User's Manual, ver. 0.02
WARNING
Do not use a pencil to set the DIP switches as the lead graphite
may short-circuit the switch.
Table 1: ACM/16/Flex16/16RJ address settings
Address
Port numbers
assigned
ACM/16RJ
Switch settings
ACM/16/Flex16
DIP Switch settings
1
2
3
1
1 - 16
1
on
on
on
2
17 - 32
2
off
on
on
3
33 - 48
3
on
off
on
4
49 - 64
4
off
off
on
5
65 - 80
5
on
on
off
6
81 - 96
6
off
on
off
7
97 - 112
7
on
off
off
8
113 - 128
8
off
off
off
Example:
The following examples show the ACM/16, ACM/Flex16 or
ACM/16RJ address switch block or switch set for:
Address 1, ports 1 through 16(default):
Address
0
1
ACM/16/Flex16
Address
1
2
3
4
5
6
7
8
ACM/16RJ
Address 2, ports 17 through 32:
Address
0
1
ACM/16/Flex16
Address
1
2
3
4
5
6
7
8
ACM/16RJ
