Intellicon-NT960/PCI User's Manual, ver. 0.02
Up to eight ACM/16's, ACM/16RJ’s and/or ACM/Flex16’s
can connect to an Intellicon-NT960/PCI Host Adapter
providing up to 128 serial ports.
Figure 2: ACM/16 module
External power supply
ACM/16 address switch
Power LED
Traffic LED
Activity LED
DB37 bus connector
Power in
Power out
connector
connector
