72
Table 8 — 30XA140-500 Electrical Data, Dual Point (High Ambient Option) (cont)
LEGEND
NOTES:
1. Units are suitable for use on electrical systems where voltage supplied to the unit
terminals is not below or above the listed minimum and maximum limits. Maximum
allowable phase imbalance is: voltage, 2%; amps 10%.
2. Cooler heater is wired into the control circuit so it is always operable as long as the
control power supply disconnect is on, even if any safety device is open.
3. For MCA that is less than or equal to 380 amps, 3 conductors are required.
For MCA between 381-760 amps, 6 conductors are required.
For MCA between 761-1140 amps, 9 conductors are required.
For MCA between 1141-1520 amps, 12 conductors are required.
Calculation of conductors required is based on 75 C copper wire.
4. Wiring for main field supply must be rated 75 C minimum. Use copper for all units.
a. Incoming wire size range for the terminal block is no. 4 AWG (American Wire Gage)
to 500 kcmil.
b. Incoming wire size range of non-fused disconnect with MCA up to 599.9 amps is
3/0 to 500 kcmil.
c. Incoming wire size range of non-fused disconnect with MCA from 600 to 799.9 amps
is 1/0 to 500 kcmil.
d. Incoming wire size range of non-fused disconnect with MCA from 800 to 1199.9 amps
is 250 kcmil to 500 kcmil.
5. Data provided circuit 1/circuit 2 where there are two circuits.
UNIT
30XA
UNIT VOLTAGE NUMBER
OF
COND
FANS
7.5 HP PUMP, 3450 RPM 10 HP PUMP, 3450 RPM CONTROL CIRCUIT
V-Hz
(3 Ph)
Supplied
MCA MOCP
ICF Rec
Fuse
Size
MCA MOCP
ICF Rec
Fuse
Size
Voltage
1 PH,
60 Hz
MCA
and
MOCP Min Max WD XL WD XL
140
230-60 207 253 6/4 383.8/235.1 600/350 660.8/414.4 — 450/300 383.8/242.3 600/350 660.8/421.6 — 450/300 115 40
200-60 187 220 6/4 422.6/259.0 700/400 756.7/473.4 — 500/300 422.6/266.9 700/400 756.7/481.4 — 500/350 115 40
460-60 414 506 6/4 191.9/117.5 300/175 330.4/207.2 962.4/578.2 225/150 191.9/121.1 300/175 330.4/210.8 962.4/581.8 225/150 115 40
575-60 518 633 6/4 147.7/ 90.7 225/125 263.9/165.6 769.9 /462.6 175/110 147.7/ 93.5 225/125 263.9/168.4 769.9/465.4 175/110 115 40
380-60 342 418 6/4 223.9/138.0 350/200 400.2/251.2 1165.2/700.2 300/175 223.9/142.4 350/200 400.2/255.5 1165.2/704.5 300/175 115 40
160
230-60 207 253 6/4 434.8/272.3 700/400 828.8/414.4 — 600/350 434.8/279.5 700/400 828.8/421.6 — 600/350 115 40
200-60 187 220 6/4 478.1/299.6 800/450 950.7/473.4 — 600/350 478.1/307.6 800/450 950.7/481.4 — 600/400 115 40
460-60 414 506 6/4 216.9/135.7 350/200 414.4/207.2 1222.4/578.2 300/175 216.9/139.3 350/200 414.4/210.8 1222.4/581.8 300/175 115 40
575-60 518 633 6/4 167.0/105.2 250/150 331.9/165.6 977.9/462.6 200/125 167.0/108.1 250/150 331.9/168.4 977.9/465.4 200/125 115 40
380-60 342 418 6/4 253.3/159.5 400/250 501.2/251.2 1480.2/700.2 300/200 253.3/163.8 400/250 501.2/255.5 1480.2/704.5 300/200 115 40
180
230-60 207 253 6/6 — — — — — — — — — — 115 40
200-60 187 220 6/6 — — — — — — — — — — 115 40
460-60 414 506 6/6 — — — — — — — — — — 115 40
575-60 518 633 6/6 — — — — — — — — — — 115 40
380-60 342 418 6/6 — — — — — — — — — — 115 40
200
230-60 207 253 6/6 — — — — — — — — — — 115 40
200-60 187 220 6/6 — — — — — — — — — — 115 40
460-60 414 506 6/6 — — — — — — — — — — 115 40
575-60 518 633 6/6 — — — — — — — — — — 115 40
380-60 342 418 6/6 — — — — — — — — — — 115 40
220
230-60 207 253 7/6 — — — — — — — — — — 115 40
200-60 187 220 7/6 — — — — — — — — — — 115 40
460-60 414 506 7/6 — — — — — — — — — — 115 40
575-60 518 633 7/6 — — — — — — — — — — 115 40
380-60 342 418 7/6 — — — — — — — — — — 115 40
240
230-60 207 253 7/6 — — — — — — — — — — 115 40
200-60 187 220 7/6 — — — — — — — — — — 115 40
460-60 414 506 7/6 — — — — — — — — — — 115 40
575-60 518 633 7/6 — — — — — — — — — — 115 40
380-60 342 418 7/6 — — — — — — — — — — 115 40
260
460-60 414 506 9/6 — — — — — — — — — — 115 40
575-60 518 633 9/6 — — — — — — — — — — 115 40
380-60 342 418 9/6 — — — — — — — — — — 115 40
280
460-60 414 506 9/7 — — — — — — — — — — 115 40
575-60 518 633 9/7 — — — — — — — — — — 115 40
380-60 342 418 9/7 — — — — — — — — — — 115 40
300
460-60 414 506 10/6 — — — — — — — — — — 115 40
575-60 518 633 10/6 — — — — — — — — — — 115 40
380-60 342 418 10/6 — — — — — — — — — — 115 40
325
460-60 414 506 9/9 — — — — — — — — — — 115 40
575-60 518 633 9/9 — — — — — — — — — — 115 40
380-60 342 418 9/9 — — — — — — — — — — 115 40
350
460-60 414 506 9/9 — — — — — — — — — — 115 40
575-60 518 633 9/9 — — — — — — — — — — 115 40
380-60 342 418 9/9 — — — — — — — — — — 115 40
400
460-60 414 506 8/12 — — — — — — — — — — 115 50
575-60 518 633 8/12 — — — — — — — — — — 115 50
380-60 342 418 8/12 — — — — — — — — — — 115 50
450
460-60 414 506 8/14 — — — — — — — — — — 115 50
575-60 518 633 8/14 — — — — — — — — — — 115 50
380-60 342 418 8/14 — — — — — — — — — — 115 50
500
460-60 414 506 8/14 — — — — — — — — — — 115 50
575-60 518 633 8/14 — — — — — — — — — — 115 50
380-60 342 418 8/14 — — — — — — — — — — 115 50
ICF — Instantaneous Current Flow
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
WD
— Wye-Delta
XL — Across-the-Line
