Fig. 15A — Unit Mounting Weights (Units with MCHX Condenser Coils)
UNITS WITHOUT PUMPS — ENGLISH
UNITS WITHOUT PUMPS — SI
30XA
UNIT SIZE
MOUNTING WEIGHT (lb)
MCHX CONDENSER COILS
A B C D Total
080 1947 1673 1670 1943 7234
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F Total
090 1201 2043 750 951 1983 1199 8127
100 1226 2098 780 981 2038 1224 8348
110 1239 2136 798 1006 2075 1229 8483
120 1272 2174 800 1007 2106 1263 8622
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H Total
140 1897 1444 864 1181 1217 883 1584 1699 10,768
160 1949 1469 878 1206 1246 899 1603 1750 11,000
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H I J Total
180 905 1484 1164 1849 1187 1224 1868 840 1289 888 12,699
200 909 1499 1188 1870 1192 1232 1879 848 1299 893 12,810
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H I J K L Total
220 813 1196 1592 1498 828 1216 1259 848 1363 1064 1237 832 13,748
240 829 1218 1617 1520 830 1218 1261 850 1371 1073 1260 849 13,897
260 495 1431 1630 763 2465 1013 1528 2380 800 1333 1386 495 15,720
280 497 1451 1663 771 2497 1015 1530 2390 803 1358 1406 497 15,878
300 502 1465 1686 786 2568 1027 1557 2454 811 1367 1417 502 16,141
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H I J K L M N Total
325 742 742 978 1531 783 2546 1067 1563 2334 804 1646 1247 742 742 17,467
350 745 745 982 1546 792 2598 1077 1589 2386 808 1651 1249 745 745 17,659
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H I J K L M N O P Total
400 847 1234 1511 2965 1255 789 2214 1071 1566 2286 747 1265 2152 991 1277 868 23,038
450 856 1179 2160 2282 905 1057 2030 2053 2711 1934 1551 1266 1440 1385 1216 876 24,901
500 843 1236 2207 2334 909 1060 2037 2060 2718 1941 1555 1269 1457 1401 1279 863 25,167
30XA
UNIT SIZE
MOUNTING WEIGHT (kg)
MCHX CONDENSER COILS
A B C D Total
080 883 759 758 882 3281
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F Total
090 545 927 340 431 899 544 3686
100 556 952 354 445 924 555 3786
110 562 969 362 456 941 558 3848
120 577 986 363 457 955 573 3911
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H Total
140 860 655 392 536 552 401 719 771 4884
160 884 666 398 547 565 408 727 794 4990
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H I J Total
180 410 673 528 839 538 555 847 381 584 403 5760
200 412 680 539 848 541 559 852 385 589 405 5811
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H I J K L Total
220 369 542 722 680 376 552 571 385 618 483 561 378 6236
240 376 552 734 690 377 553 572 386 622 487 572 385 6304
260 225 649 740 346 1118 460 693 1079 363 605 629 225 7130
280 225 658 754 350 1133 461 694 1084 364 616 638 225 7202
300 228 664 765 357 1165 466 706 1113 368 620 643 228 7322
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H I J K L M N Total
325 337 337 444 695 355 1155 484 709 1058 365 746 565 337 337 7923
350 338 338 446 701 359 1179 488 721 1082 367 749 567 338 338 8010
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H I J K L M N O P Total
400 384 560 685 1345 569 358 1004 486 710 1037 339 574 976 450 579 394 10 450
450 388 535 980 1035 411 479 921 931 1230 877 704 574 653 628 551 397 11 295
500 382 561 1001 1059 412 481 924 934 1233 880 705 576 661 635 580 391 11 416
