40
SINGLE PUMP UNITS — ENGLISH
SINGLE PUMP UNITS — SI
*Condenser Coil: Copper Fins/Copper Tubing.
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) — Cu/Cu*
A B C D E F Total
090 1394 3139 1280 1093 2330 1392 10,627
100 1420 3201 1317 1117 2382 1418 10,854
110 1433 3244 1339 1139 2416 1424 10,994
120 1467 3282 1342 1142 2449 1458 11,139
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) — Cu/Cu*
A B C D E F G H Total
140 2188 1735 1804 1800 1273 1004 1876 1990 13,669
160 2242 1762 1821 1831 1299 1019 1896 2043 13,912
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) — Cu/Cu*
A B C D E F Total
090 632 1424 581 496 1057 631 4820
100 644 1452 597 507 1080 643 4923
110 650 1471 607 517 1096 646 4987
120 665 1489 609 518 1111 661 5053
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) — Cu/Cu*
A B C D E F G H Total
140 992 787 818 816 577 455 851 903 6200
160 1017 799 826 830 589 462 860 927 6310
30XA090-120 30XA140,160
Fig. 15C — Unit Mounting Weights (Units with Cu/Cu Condenser Coils) (cont)
a30-4420 a30-4421
A B C
F E D
COOLER SIDE
COMPRESSOR SIDE
A B C D
H G F E
COOLER SIDE
COMPRESSOR SIDE
